Overview:Application● The following materials are dried in the pharmaceutical, food, chemical and other industries.● Suitable for paste, paste and powder materials.● Heat-sensitive materials requiring low-temperature drying.● Easily oxidized, explosive, st…
Application
● The following materials are dried in the pharmaceutical, food, chemical and other industries.
● Suitable for paste, paste and powder materials.
● Heat-sensitive materials requiring low-temperature drying.
● Easily oxidized, explosive, strongly irritating, and highly toxic materials.
● Materials requiring recovery of organic solvents.
Technical specifications
| Project | Model | ||||||
| Name | Unit | ZPG-500 | ZPG-750 | ZPG-1000 | ZPG-1500 | ZPG-2000 | ZPG-3000 |
| Working volume | L | 300 | 450 | 600 | 900 | 1200 | 1800 |
| Heating area | m2 | 6 | 7.6 | 9.3 | 12.3 | 14.6 | 19.3 |
| Stirring speed | rpm | 6-30 Stepless speed regulation | |||||
| Power | kw | 4 | 5.5 | 5.5 | 7.5 | 11 | 15 |
| Interlayer design pressure (hot water) | Mpa | ≤0.3 | |||||
| Vacuum degree in cylinder | Mpa | -0.09～0.096 | |||||
Note: The amount of water evaporation is related to the characteristics of the material and the temperature of the hot inlet and outlet. When the outlet temperature is 90oC, the water evaporation curve is shown in the above figure (for reference for selection). As the product is continuously updated, the relevant parameters will be changed without prior notice.
