Features
● Fast drying speed, especially suitable for heat-sensitive materials.
● The resulting product is spherical particles with uniform particle size, good fluidity and solubility, high product purity and good quality.
● Wide range of use, hot air drying, granulation, cooling granulation, spray crystallization, spray reaction, etc. can also be carried out.
● It can be equipped with a fine powder return and re-wet agglomeration system to meet the user's requirements for the particle size of the material.
● Simple and stable operation, convenient control, easy to realize automatic operation, product particle size, bulk density and water powder can be adjusted within a certain range.
Application
Food, medicine, chemicals, dyeing, ceramics, biochemical, pesticides, plastics, etc. are suitable for liquids with corresponding fluidity.
Technical specifications
| Model | Unit | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| Water evaporation | kg | 50 | 100 | 150 | 200 | 300 | 500 | 1000 |
| Dimensions (Ф×H) | mm | 1600×8900 | 2000×11500 | 2400×13500 | 2800×14800 | 3200×15400 | 3800×1880 | 4600×22500 |
| High pressure pump pressure | mPa | 2～10 | ||||||
| Power | KW | 8.5 | 14 | 22 | 24 | 30 | 82 | 30 |
| Inlet air temperature | oC | 140～350 | ||||||
| Product moisture content | % | ＜5 (up to 0.5) | ||||||
| Material recovery | % | ＞97 | ||||||
| Electric heating | KW | 75 | 120 | 150 | When the temperature is lower than 200, according to actual technology | |||
| Electricity plus steam | Mpa+KW | 0.5+54 | 0.6+90 | 0.6+108 | ||||
| Hot blast stove | Kcal/h | 100000 | 150000 | 200000 | 300000 | 400000 | 500000 | 1200000 |
Note: Some parameters are adjusted according to different materials during the design, and the design shall prevail.
