Overview:Product UsageThe machine is suitable for pharmaceutical, chemical, metallurgical, food, construction and other industries. It can process hard and difficult to pulverize materials, including pulverizing plastics, copper wires, Chinese herbal medicines…
Product Usage
The machine is suitable for pharmaceutical, chemical, metallurgical, food, construction and other industries. It can process hard and difficult to pulverize materials, including pulverizing plastics, copper wires, Chinese herbal medicines, rubber, etc., and can also be used as a supporting equipment for the pre-processing of micro-pulverizers and ultra-fine pulverizers.
working principle
The material is fed into the crushing chamber from the feed hopper, and the rotating knife and the fixed knife are sheared and crushed at the same time by the impact of the blade and the knife seat. Due to the action of the rotating centrifugal force, the material automatically flows out from the outlet.
Technical Parameters
| Model number | CSJ-250 | CSJ-500 |
| Feed size | ≤100 | ≤100 |
| Discharge particles | 0.5-20 | 0.5-20 |
| Spindle speed | 940 | 1000 |
| Work rate | 4 | 11 |
| Yield | 50-300 | 80-800 |
| Dimensions | 860×650×1020 | 1120×1060×1050 |
