Overview:Scope of application This machine is used in the pharmaceutical, food, granular, chemical, solid beverage and other industries to make the mixed materials into the required particles, especially suitable for materials with higher viscosity.Performance…
Scope of application
This machine is used in the pharmaceutical, food, granular, chemical, solid beverage and other industries to make the mixed materials into the required particles, especially suitable for materials with higher viscosity.
Performance characteristics
All parts in contact with the material are made of stainless steel, with beautiful appearance, reasonable structure, high granulation molding rate, beautiful granules, automatic discharging, to avoid particle damage caused by manual discharging, and suitable for flow operation.
Technical specifications
| Grinding knife size(mm) | 250 | 300B | 300D |
| Particle diameter（mm） |
Φ2-2.2 （According to user needs） |
Φ1.2-3 （According to user needs） |
0.5-6 （According to user needs） |
| Dimensions（mm） | 700×540×1300 | 880×640×1300 | 1300×800×1200 |
| Motor Power（kw） | 3 | 4 | 7.5-6 |
| weight（kg） | 350 | 400 | 780 |
|
Production capacity（kg/h） |
100-200 | 140-400 | 300-600 |
Note: Due to material differences, the output in the table is for reference only
